60VDC TO DC 500W Dual output full isolation CONVERTER

FOB Reference Price:Get Latest Price
$16.00 - $80.00 / Pieces | 20 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 300 >300
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
persino
Model Number:
PSCN-60VDC-DC500W
Output Power:
500W
Output Type:
Dual
Size:
customized
Weight:
customized
Input Voltage:
56.2-95V
Output Voltage:
13.8±0.2V
Type:
DC/DC Converters
Output Frequency:
≥85%
Output Current:
54±2A
Color:
Black
Rated voltage:
60V
operating ambient temperature:
-20℃~+60℃
Supply Ability
Supply Ability:
1000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
carton
Port
ningbo/shanghai
Lead Time :
Quantity(Pieces) 1 - 300 >300
Est. Time(days) 15 To be negotiated
Product Description

Technical parameter


1.Rated power efficiency:≥85%

2.Load rate:0-100% continue

3.Peak power:120%

4.Working environment temperature:-20℃~+60℃

5.Storage temperature:-20℃~+70℃

6.Anti grade:Match SAEJ1378

7.Salt mist:GB/T2423.17-2008

8.Input to output withstand voltage:1500Vac(2100Vdc)/10s leakage current<10mA

9.Input withstand voltage for enclosure:1000V DC/10s leakage current<10mA

10.The input to output is tested at 1000V DC < 10mA, and the insulation resistance is 50M ohm.

11.Input undervoltage protection

12.Output short circuit protection

13.Temperature protection: the shell temperature reaches 80-90 degrees, DC protection has no output, the shell temperature drops to 60-75 degrees DC automatic recovery output

Rated input voltage
60v
Input voltage range
56.2-95v
Input under voltage protect
56.2±2V
Unload output voltage
13.8±0.2v
Full load output voltage
13.8±0.2v
Rated output power
500w
Max output current
54±2A
Auxiliary output power
120W
Auxiliary output current
≥10A
